Chapter 9: Effects
Page 138
By installing the optional effect board (EB16), you can carry out various effect processing for each
sound.
Editing Effects
Hold down SHIFT and press MIXER (numeric key 7), then select “DRUM 1-4”.
The mixer display will appear.
Press
FXedit [F5] to display the effects screen.
ON/OFF DRUM 2 DRUM 2 DRUM 1 DRUM 1 DRUM 3 DRUM 3 DRUM 4 DRUM 4 SETUP
Drum:1 Pgm: 1-NewPgm-A
Edit:MULTI FX1
M1 REV MIX
DIST FILT MOD ECHO
The effect board EB16 contains 2 multi-effects and 2 reverbs. The multi-effect consists of mod-
ules for each effect and each module can be edited or rearranged.
The effect settings of MULTI FX1, MULTI FX2, REVERB 1 and REVERB 2 can be set individually.
Drum: For selection of the 4 drum programs that can be used simultaneously on the
MPC2000XL. Setting the effects assigned to the selected drum program is
done here.
Note: Each drum program can have its own effect setting, but only one effect
setting can be used.
Pgm: For display of the program assigned to the drum selected in the Drum: field.
The program can be changed here.
Edit: Selects the effect to be edited.
Turning Each Effect On or Off
Each multi-effect contains 5 types of effects and a MIX setting. You can turn each effect and mix
setting on and off.
Use the CURSOR LEFT/RIGHT keys to select the effect that you want to turn on or off.
ON/OFF DRUM 2 DRUM 2 DRUM 1 DRUM 1 DRUM 3 DRUM 3 DRUM 4 DRUM 4 SETUP
Drum:1 Pgm: 1-NewPgm-A
Edit:MULTI FX1
M1 REV MIX
FILT MOD ECHO DIST
Press ON/OFF [F6] to switch between on and off.
ON/OFF DRUM 2 DRUM 2 DRUM 1 DRUM 1 DRUM 3 DRUM 3 DRUM 4 DRUM 4 SETUP
Drum:1 Pgm: 1-NewPgm-A
Edit:MULTI FX1
M1 REV MIX DIST
FILT MOD ECHO
When MIX is off, all of the effect sounds will be muted regardless of the on/off status of each effect.
