62
F A U L T V A
B A T T E R Y >
F A U L T V A
E N D O F L I N E 6 >
F A U L T V A
O U T P U T O P E N 3 >
F A U L T V A
O U T P U T S H O R T 6 < >
F A U L T V A
D S >
F A U L T V A
G R O U N D F A U L T <
F A U L T E 1
G R O U N D F A U L T < >
F A U L T E 2
D S D C >
Failure Location: Battery
Failure detected in the battery.
Failure Location: Speaker Line
F a i l u r e d e t e c t e d i n t h e s p e a k e r l i n e c o n n e c t e d t o t h e
VM-3360VA or VM-3240VA.
(The speaker line No. can be displayed only when an EOL unit
is connected to each individual speaker line.)
Failure Location: Speaker Line (Open or Short Circuit)
Open circuit caused in speaker Line 3 of the VM-3360VA or
VM-3240VA.
S p e a k e r L i n e 6 o f t h e V M - 3 3 6 0 V A o r V M - 3 2 4 0 V A i s
short-circuited.
Failure Location: Speaker Line (Ground Fault)
Ground fault caused in a speaker connected to the VM-3240VA
or VM-3360VA.
Ground fault caused in a speaker connected to the VM-3240E
or VM-3360E.
Failure Location: Emergency Power Supply (VX-2000DS)
VX-2000DS has failed or is not connected.
Failure detected in the VX-2000DS’ DC output.
