132
Lead-acid Battery
DC power
output terminals
(–)
(–)
(–)(–)(+)(+)
(–)(–)(+)(+)
(+)
(–)
(+)
DC power
input terminals
VP-2241
PA LINK VP-200VX
28 V 4.8 A
DC POWER IN
PA OUT (SP LINE)
C H
VP-2241
PA LINK VP-200VX
28 V 4.8 A
DC POWER IN
PA OUT (SP LINE)
C H
VM-3240E/3360E
24V MAX150A
BATTERY POWER IN
( ) ( )
( )
230V
50/60Hz 240W
6 1 5 4 3 2 6 1 5 4 3 2
DC POWER OUT (+) MAX 25A (DC 20V-40V) PS IN ( + ) MAX 25A (DC20V-40V)
DS – SF FUSE
LINK
DETECT(VX-200PS)
OFF ON ON OFF
THERMISTOR
PS3 PS2
1,2:PS1
PS IN
5,6:PS3
3,4:PS2
Note
Make PS2 and PS3 switch settings according to the total number of connected power supply units VX-200PS and VM-3240VA/3360VA
(power supply unit incorporated); set PS2 to ON for 2 units, and PS2 and PS3 to ON for 3 units.
Note that these power supply units should be connected to the PS IN (+) terminals 1 and 2 for the 1st unit, 3 and 4 for the 2nd unit, and 5
and 6 for the 3rd unit.
See “Note” below.
RJ45 male connector
VX-2000DS
VX-200PS
Cat. 5 STP
Caution
The charging current from the VX-2000DS is 5 A maximum.
Applicable Batteries: Panasonic LC-X1265PG/APG
230 V AC
50/60 Hz
230 V AC
50/60 Hz
230 V AC
50/60 Hz
230 V AC
50/60 Hz
6-I/O AWG
d
c
a
a
b
d
c
d
c
c
VM-3240VA/3360VA
From VX-2000DS
From VX-2000DS
From VX-2000DS
From VX-2000DS
d
d
b
c
d
d
Note
Remove the short bar attached at the factory.
14.11. Connecting Power Supply Equipment
