Toa VM-3000 Series User Manual
Page 134
134
VM-3240VA
VM-3240E
VM-3240E
VM-3240E
Lead-acid Battery
VX-2000DS
VP-2241
EXT. AMP INPUT
EXT. AMP
INPUT
EXT. AMP
INPUT
EXT. PA LINK
DC POWER
VM LINK
DC POWER
DS LINK
VM LINK
PA OUT
PA OUT
VM LINK
DC POWER
DS LINK
Lead-acid Battery
VX-2000DS
EXT. AMP
INPUT
VX-200PS
System including one VP amplifier connected as a standby amplifier
One VX-2000DS is required every 3 VM amplifiers.
Note
Connect the VX-200PS to the VX-2000DS to
which the VP amplifier is connected.
Number of VM amplifiers
1
2
3
4
5
6
7
8
9
10
Number of VX-2000DS'
1
2
3
4
Number of VX-200PS'
0
1
Below is an example showing that 2 VX-2000DSs and 1 VX-200PS are required in a system including 4 VM
amplifiers.
