Toa VM-3000 Series User Manual
Page 111
111
•
In a system consisting of a single VM-3240VA/3360VA without VM-3240E/3360E, when the VX-2000DS
Emergency Power Supply unit supplies power to the RM-300MF/320F, the connectable number of the RM-
320Fs is reduced, being up to 2 RM-320Fs.
VM-3240VA/3360VA
RM-300MF RM-320F
RM-300MF RM-320F
VX-2000DS
•
In the system above, to connect 3 or more RM-320Fs, one VX-200PS is needed.
VM-3240VA/3360VA
RM-300MF RM-320F
VX-2000DS
RM-300MF RM-320F
VX-200PS
•
By supplying power to the RM-300MF/320F from the VX-2000DS, the RM-300MF/320F can be operated on
the backup power even in case of AC power failure.
VM-3240VA/3360VA
RM-300MF
RM-300MF RM-320F
VX-2000DS
[Limit on the number of remote microphones determined by system configurations]
Note
Red lines are DC power lines.
