See figure 3-39, See figure 3-40 – TeeJet SmartPad II User Guide User Manual
Page 84
3-30
Chapter 3 - Real-Time Guidance
Lightbar Setup
SmartPad II
Software Version 4.03
Figure 3-39: Swath Display Mode
Figure 3-40: Vehicle Display Mode
Center LED stack equals current
guideline.
Moving LED represents the vehicle
position.
Moving LED represents the
current guideline.
Center LED stack represents
the vehicle.
