2-6

Chapter 2 - Software Overview
SmartPad II Software Overview

Fieldware for Smartpad II

Software Version 4.03

Figure 2-3: Pick Dialog Box Example

Figure 2-4: Alpha-Numeric Dialog Box Example

Current setting displayed.

Description of the displayed
setting.

Dialog cell with current
value displayed.
