Form I-F/B, P/N 98126 R21, Page 3

Installation should be done by a qualified agency in accordance with the instructions

in this manual and in compliance with all codes and requirements of authorities hav-

ing jurisdiction. The instructions in this manual apply only to Model F and Model B unit

heaters.

The gas-fired unit heaters covered in this manual are design-certified by the Canadian

Standards Association (CSA) to ANSI Z83.8 and CSA 2.6 for industrial/commercial

installations in the United States and Canada. All heaters are available for use with

either natural or propane gas. The type of gas, the firing rate, and the electrical char-

acteristics are on the unit rating plate.
These units must be installed in accordance with local building codes. In the absence

of local codes, in the United States, the unit must be installed in accordance with the

National Fuel Gas Code ANSI Z223.1 (latest edition). A Canadian installation must be

in accordance with the CSA B149 Installation Codes for Gas Burning Appliances and

Equipment (latest edition). These codes are available from CSA Information Services,

1-800-463-6727. Local authorities having jurisdiction should be consulted before instal-

lation is made to verify local codes and installation procedure requirements.

Special Installations (Aircraft Hangars/Garages)

Installations in aircraft hangars should be in accordance with ANSI/NFPA No. 409 (lat-

est edition), Standard for Aircraft Hangars; in public garages in accordance with ANSI/

NFPA No. 88A (latest edition), Standard for Parking Structures; and for repair garages

in accordance with ANSI/NFPA No. 88B (latest edition), Standard for Repair Garages.
In Canada, installations in aircraft hangars should be in accordance with the require-

ments of the enforcing authorities, and in public garages in accordance with CSA B149

codes.

Refer to the limited warranty form in the "Literature Bag"

WARRANTY: Warranty is void if......

a. Unit Heaters are used in atmospheres containing flammable vapors or

atmospheres containing chlorinated or halogenated hydrocarbons or

airborne silicone substances.

b. Wiring is not in accordance with the diagram furnished with the heater.
c. Unit is installed without proper clearances to combustible materials

or located in a confined space without proper ventilation and air for

combustion. (See Paragraphs 2.2 and 4.1.)

d. Fan-type unit heater is connected to a duct system.

1.2 General

Installation

Information

1.3 Warranty

1.4 Installation

Codes

2. Unit Heater

Location

2.1 General Recommendations

WARNING: Avoid installing a unit heater in extremely drafty

areas. Extreme drafts can shorten the life of the heat exchanger

and/or cause safety problems.

For best results, the heater should be placed with certain rules in mind. In general, a

unit should be located from 8 to 12 feet (2.4-3.7M) above the floor. Units should always

be arranged to blow toward or along exposed wall surfaces, if possible. Where two or

more units are installed in the same room, a general scheme of air circulation should

be maintained for best results.
Suspended heaters are most effective when located as close to the working zone as

possible, and this fact should be kept in mind when determining the mounting heights

to be used. However, care should be exercised to avoid directing the discharged air

directly on the room occupants.
Partitions, columns, counters, or other obstructions should be taken into consideration

when locating the unit heater so that a minimum quantity of airflow will be deflected by

such obstacles.
