Form I-F/B, P/N 98126 R21, Page 11

Size

A

B

C

H

D

E

F

D

G

AC

H

I

J

K

AB

L

Hanger

Natural Propane

25

766

344

1102

799

148

367

1559

483

102 Rnd

261

406

13

13

50

766

344

1270

799

148

367

1559

483

102 Rnd

261

406

13

13

75

766

395

1270

799

148

367

1559

483

127 Oval

267

406

13

13

100

766

446

1270

799

148

367

1559

483

152 Oval

328

406

13

13

125

813

592

1207

799

148

367

1674

456

178 Oval

367

406

13

13

165

1020

516

1549

913

124

495

1934

595

203 Oval

363

610

13

13

200

1020

592

1689

913

124

495

1934

595

203 Oval

366

610

13

13

250

1020

732

1689

913

124

495

1934

544

254 Oval

314

610

13

13

300

1020

732

1689

913

124

495

1934

544

254 Oval

314

610

19

13

400

1020

941

1689

913

124

495

1934

544

305 Oval

330

610

19

13

Size

M

A

N

A

P

A

R

A

S

B

T

B

U

A

W

A

X

E

Hanger

Y

Z

25

94

532

481

133

273

214

375

157

793

546

702

50

94

532

481

133

273

214

375

157

793

546

702

75

69

532

481

133

324

214

375

157

793

546

702

100

44

532

481

133

375

214

375

157

793

546

702

125

34

532

481

133

521

214

521

157

908

546

724

165

72

659

641

184

445

291

521

202

932

686

934

200

34

659

641

184

521

291

521

202

932

686

934

250

150

1030

641

184

660

291

660

202

932

686

975

300

150

1030

641

184

660

291

660

202

932

686

975

400

172

1284

641

184

870

291

870

202

932

686

975

Dimensions - mm

NOTES:

A

When equipped with optional blower cabinet.

B

When equipped with optional duct flange.

C

Dimension includes a 3/4" flange on the rear of the blower cabinet.

D

Use with 4-point suspension without blower cabinet. If installing hanger kit Option CK19, suspension points change; see Paragraph 5.2.1.

E

Use with 4-point suspension with blower cabinet.

F

Contactor is standard on Models 300 and 400; optional on other sizes.

G

Contactor location with optional three phase motors on Sizes 50, 75, 100 and 125.

H

Deduct 6-5/8" (168mm) on Sizes 50, 75, and 100 when equipped with direct drive motor.

5. Hanging the

Heater

5.1 Weights

Before suspending the unit, check the supporting structure to be used to verify that it

has sufficient load-carrying capacity to support the weight of the heater.

NOTE: If the installation

includes an optional

stepdown transformer kit

(Option CF or CG), the

stepdown transformer

bracket is part of the

heater suspension and

must be installed prior to

hanging the heater. Follow

the instructions on the

installation sheet included

with the option kit.

Net Weight - lbs and kg

Model Type

Size

25

50

75 100 125 165 200 250 300 400

Fan

lbs

72

79

88

97 127 149 170 204 221 276

kg

33

36

40

44

58

68

77

93 100 125

Blower

lbs

93 100 114 126 150 201 235 273 296 390

kg

42

45

52

57

68

91 107 124 134 177

5.2 Lifting and Suspending

A

fan-type unit heater is equipped with standard two-point suspension. A 3/8-16

threaded hanger bracket assembly is located on each side of the heater. If a fan-type

unit has been ordered with optional, factory-installed, four-point suspension (Option

BJ6), it will have two threaded hanger brackets on each side.

A

blower-type heater is equipped with standard four-point suspension. Two 3/8-16

threaded hanger bracket assemblies are located on each side of the unit. Each hanger

bracket assembly is designed for threaded rod attachment.
For both "standard" and "optional" suspension point dimensions, see Dimension

Tables in Paragraph 4.2. (Note: If installing Option CK19 hanger kit, suspension points

change; see

FIGURE 11, page 13.)
