ALT_B-PLT_A-PLT_F-BA-e-1333 7
KERN PLT 420-3F PLT 4200-2F
Weighing range (max) 420 g 4200 g
Readability (d) 1 mg 10 mg
Reproducibility 1 mg 10 mg
Linearity ± 4 mg ± 40 mg
Stabilization time (typical) 2 s 2 s
Minimum unit weight at
piece counting
> 5 mg > 50 mg
Warm-up time 4 hours
Adjustment weight internal
Reference quantities at
piece counting
10, 25, 50, 100, freely selectable
Weighing Units
ct, g, gn, lb, mo, oz, ozt,
tl (HK), tl (Singap. Malays), tl (Tw), tol
Input Voltage 220 - 240V AC 50 Hz
Secondary voltage
powerpack
9 V 1000 mA, DC
Operating temperature + 5° C / + 35° C
Humidity of air max. 80 % (not condensing)
Housing (B x D x H) mm 210 x 340 x 160
Dimensions of windshield Ø 150, 60 high (inside)
Ø 160, 70 high (outside)
Weighing pan (stainless
steel)
Ø 11 cm Ø 16 cm
Weight kg (net) 4 kg
Interface RS 232C
Underfloor weighing device -
