6 ALT_B-PLT_A-PLT_F-BA-e-1333
KERN PLT 720-3A PLT 1200-3A PLT 6200-2A
Weighing range (max) 720 g 1200 g 6200 g
Readability (d) 1 mg 1 mg 10 mg
Reproducibility 1 mg 1 mg 10 mg
Linearity ± 2 mg ± 2 mg ± 30 mg
Stabilization time (typical) 2 s 2 s 2 s
Minimum unit weight at
piece counting
> 5 mg > 5 mg > 50 mg
Warm-up time 4 hours 8 hours 4 hours
Adjustment weight internal
Reference quantities at
piece counting
10, 25, 50, 100, freely selectable
Weighing Units
ct, dwt, g, gn, lb, mo, oz, ozt,
tl (HK), tl (Singap. Malays), tl (Tw)
Input Voltage 220 - 240V AC 50 Hz
Secondary voltage
powerpack
24 V AC, 500mA
Operating temperature + 5° C / + 35° C
Humidity of air max. 80 % (not condensing)
Housing (B x D x H) mm 210 x 340 x 160 210 x 340 x 100
Dimensions of windshield Ø 150, 60 high (inside)
Ø 160, 70 high (outside)
-
Weighing pan (stainless
steel)
Ø 11 cm Ø 16 cm
Weight kg (net) 4.5 kg
Interface RS 232C
Underfloor weighing device Eyelet
