6
User fingerprint
Transaction log
PC FRIS SERVER PC
TCM
S V2 TCM
S V2
1 2 3
4 5 6
7 8
0 9
ESC
OK MENU
User
fingerprint
Transaction
log
FRIS SERVER 1 TA200 Plus
R2
TCM
S V2
InteRne t
oR
wan
1 2 3
4 5 6
7 8
0 9
ESC
OK MENU
User
fingerprint
Transaction
log
FRIS SERVER 1
TA200 Plus
R2
TCMS in HQ Centralization
Station
If the fingerprint fails to be verifed, the FRIS server will return a message to the FingerTec
terminals to alert the user to try again.
FRIS SeRveR wIth FIngeRtec tcMS v2
Computers with FingerTec TCMS V2 installed can access into the FRIS server to pull trans-
action logs of all users. These transaction logs will be arranged according to the clocking
rules, which have been predefined in TCMS V2.
TCMS V2 can produce user reports and the attendance data can be exported into various
formats (.txt, .xls or ODBC manager) for payroll calculation.
The transaction log pulling process is from FRIS to a computer and it is irreversible. This is
to ensure that the transaction data stored in FRIS server is original; therefore the transac-
tion logs pulled into any computer with the TCMS will always be correct and complete.
The FRIS server can support transaction logs of more than one computer with TCMS V2
installed. Another computer with TCMS V2 can access the FRIS server to pull transaction
data, even if the first computer has pulled the data before. FRIS can share its transaction
database with all computers installed with TCMS V2 and have accessibility to FRIS server.
This structure is suitable for an installation site, where there are several people who have
the authority to pull transaction logs and view the attendance data.
Multi Server Structures
MultI FRIS SeRveR wIth FIngeRtec tcMS v2
It is recommended to use different FRIS servers for different zones. The logic behind this
is to allow both FRIS servers to be independent during the fingerprint verification process
and transaction log storing process.
