FDwfDigitalOutEnableGet(HDWF hdwf,
int
idxChannel, BOOL *pfEnable)
Parameters:
- hdwf – Interface handle.
- idxChannel – Channel index.
- pfEnable – Pointer to variable to receive enabled state.
The function above is used to verify if a specific channel is enabled or disabled.
FDwfDigitalOutOutputInfo(
HDWF hdwf,
int
idxChannel,
int
*pfsDwfDigitalOutOutput)
Parameters:
- hdwf – Interface handle.
- idxChannel – Channel index.
- pfsDwfDigitalOutOutput – Pointer to variable to receive the supported output modes.
The function above returns the supported output modes of the channel. They are returned (by reference) as a bit
field. This bit field can be parsed using the IsBitSet Macro. Individual bits are defined using the
DwfDigitalOutOutput constants in DWF.h:
DwfDigitalOutOutputPushPull: Default setting.
DwfDigitalOutOutputOpenDrain: External pull needed.
DwfDigitalOutOutputOpenSource: External pull needed.
DwfDigitalOutOutputThreeState: Available with custom and random types.
FDwfDigitalOutOutputSet(HDWF hdwf,
int
idxChannel, DwfDigitalOutOutput v)
Parameters:
- hdwf – Interface handle.
- idxChannel – Channel index.
- v – Output mode.
The function above specifies output mode of the channel.
FDwfDigitalOutOutputGet(HDWF hdwf,
int
idxChannel, DwfDigitalOutOutput *pv)
Parameters:
- hdwf – Interface handle.
- idxChannel – Channel index.
- pfEnable – Pointer to variable to receive enabled state.
The function above is used to verify if a specific channel output mode.
