FDwfAnalogInTriggerConditionInfo(HDWF hdwf,

int *

pfstrigcond)

Parameters:
-

hdwf – Interface handle.

pfstrigcond – Variable to receive the supported trigger conditions.

The function above returns the supported trigger type options for the instrument. They are returned (by
reference) as a bit field. This bit field can be parsed using the IsBitSet Macro. Individual bits are defined using the
TRIGCOND constants in dwf.h. These trigger condition options are:



trigcondRisingPositive (This is the default setting):
o For edge and transition trigger on rising edge.
o For pulse trigger on positive pulse.



trigcondFallingNegative:
o For edge and transition trigger on falling edge.
o For pulse trigger on negative pulse.

FDwfAnalogInTriggerConditionSet(HDWF hdwf, TRIGCOND trigcond)

Parameters:
-

hdwf – Interface handle.

trigcond – Trigger condition to set.

The function above is used to set the trigger condition for the instrument.

FDwfAnalogInTriggerConditionGet(HDWF hdwf, TRIGCOND *ptrigcond)

Parameters:
-

hdwf – Interface handle.

ptrigcond – Variable to receive the current trigger condition.

The function above is used to set the trigger condition for the instrument.

FDwfAnalogInTriggerLevelInfo(

HDWF hdwf,

double

*pvoltsMin,

double

*pvoltsMax,

int

*pnSteps)

Parameters:
-

hdwf – Interface handle.

pvoltsMin – Variable to receive the minimum voltage level.

pvoltsMax – Variable to receive the maximum voltage level.

pnSteps – Variable to receive the number of voltage level steps.

The function above is used to retrieve the range of valid trigger voltage levels for the AnalogIn instrument in Volts.
