The global trigger bus allows multiple instruments to trigger each other. These trigger source options are:
Trigger Source Options Trigger Source Function
trigsrcNone
The trigger pin is high impedance, input. This is the default
setting.
trigsrcPC
Trigger from PC, this can be used to synchronously start
multiple instruments.
trigsrcDetectorAnalogIn Trigger detector on analog in channels.
trigsrcDetectorDigitalIn Trigger on digital input channels.
trigsrcAnalogIn Trigger on device instruments, these output high when running.
trigsrcDigitalIn Trigger on device instruments, these output high when running.
trigsrcDigitalOut Trigger on device instruments, these output high when running.
trigsrcAnalogOut1 Trigger on device instruments, these output high when running.
trigsrcAnalogOut2 Trigger on device instruments, these output high when running.
trigsrcAnalogOut3 Trigger on device instruments, these output high when running.
trigsrcAnalogOut4 Trigger on device instruments, these output high when running.
trigsrcExternal1 External trigger signal .
trigsrcExternal2 External trigger signal .
trigsrcExternal3 External trigger signal .
trigsrcExternal4 External trigger signal .
