FDwfAnalogOutRepeatTriggerSet(HDWF hdwf,
int idxChannel, BOOL fRepeatTrigger)
Parameters:
-
hdwf – Open interface handle on a device.
- idxChannel – Channel index.
- fRepeatTrigger – Boolean used to specify if the trigger should be included in a repeat cycle.
The function above is used to set the repeat trigger option. To include the trigger in wait-run repeat cycles, set
fRepeatTrigger to TRUE. It is disabled by default.
FDwfAnalogOutRepeatTriggerGet(
HDWF hdwf,
int idxChannel, BOOL *pfRepeatTrigger)
Parameters:
-
hdwf – Open interface handle on a device.
- idxChannel – Channel index.
- pfRepeatTrigger – Pointer to variable to receive the repeat trigger option.
The function above is used to verify if the trigger has been included in wait-run repeat cycles.
FDwfAnalogOutMasterSet(HDWF hdwf,
int idxChannel, int idxMaster)
Parameters:
-
hdwf – Open interface handle on a device.
- idxChannel – Channel index.
- idxMaster – Node index.
The function above sets the state machine master of the channel generator. With channel index -1, each enabled
Analog Out channel will be configured to use the same, new option.
FDwfAnalogOutMasterGet(HDWF hdwf,
int idxChannel, int *pidxMaster)
Parameters:
-
hdwf – Open interface handle on a device.
- idxChannel – Channel index.
- pidxMaster – Pointer to variable to receive parameter.
The function above is used to verify the parameter.
