Creating desired tone
Preparations
■* CD • Play the desired source.
• Press the
EQ.EFFECT key to switch
■"ES the graphic equalizer effect on.
TUNER • Press the DISPLAY key to display the
graphic equalizer display. -E9
To increase
mEouENcY^ frequency
2 Select the frequency band to be adjusted.
T(
UENCY fri
• Select the equalizer curve with the closest pattern to the curve to be
created.
• When the FLAT key is pressed, a curve can be created from a flat
condition.
Properties of frequency bands
3 Adjust the level of the frequency band.
To increase level
To decrease level
Low
frequency bands
63-160 Hz Musical instruments in the low bands
sound with stable feeling.
Medium
frequency bands
400 Hz~2.5kHz
The vocal of singers seem to come to the
front or go to the deep depending on the
level adjustment.
High
frequency bands
6.3 kHz
When the level is increased, the sounds
of violin, flute, etc., become brighter.
Ultra-high
frequency bands
16 kHz The triangle, cymbal, etc. sounds brighter
and the sound become more delicate.
■ If there is another frequency band to be adjusted, repeat steps 2 and
3 for that band.
Storing the desired tone in memory
Preset the user-created equalizer curve. "MEMORY" lights.
!BHHZ
• Perform step ® while the MEMORY indicator is blinking.
• The user-created equalizer curve is preset under the pressed num­
ber as one of the MANUAL patterns.
• If an equalizer curve has already been preset under the pressed key,
it will be replaced by the new equalizer curve.
To clear the equalizer curve created and stored by the user
Select the MANUAL patterns with the R/M key and hold the key
under which the curve to be cleared has been stored. It will be cleared
and the equalizer curve originally preset in the unit will be recalled.
Presence effects
Various modes for reproducing the effects of pres­
ence are availabie. Select the mode according to the
piayed source or the component in your system.
DEPTH modes -Ea 1
