Device Specific Configuration Menu Screen
2E43-51/2E43-51R User’s Guide 5-39
3. Use the arrow keys to highlight the SAVE command at the bottom of
the screen.
4. Press ENTER. The message “SAVED OK” is displayed.
5.10.3 Setting (Enabling or Disabling) the Port Status
To set the status of an interface (port), proceed as follows:
1. Use the arrow keys to highlight the Status field of the port.
2. Use the SPACE bar to toggle to either ENABLED or DISABLED.
3. Use the arrow keys to highlight the SAVE command at the bottom of
the screen.
4. Press ENTER. The message “SAVED OK” displays.
5.11 DEVICE SPECIFIC CONFIGURATION MENU
SCREEN
The Device Specific Configuration Menu screen, Figure 5-18 , allows the
user to select one of five screens to configure ports or check system
resources specific to the 2E43-51.
NOTE
The PORT REDIRECT FUNCTION menu item on the Device
Specific Configuration Menu screen does not display if the
operational mode of the device is set to 802.1Q SWITCHING.
The PORT REDIRECT FUNCTION and BROADCAST
SUPPRESSION menu items do not display if the operational
mode is set to SECURE FAST VLAN.
Section 5.7.9 provides instructions on setting the operational
mode.
