Repeater Statistics Screen
2E43-51/2E43-51R User’s Guide 5-81
3. Press ENTER (neither the RMON Index # field nor the statistics will
change until ENTER is pressed).
5.24.2 Using the Clear Counters Command
To reset all the statistics counters of the selected interface to zero, perform
the following steps:
1. Use the arrow keys to highlight the CLEAR COUNTERS field.
2. Press ENTER, the counters for the selected index are reset to zero.
5.25 REPEATER STATISTICS SCREEN
Operating statistics for each repeater port (1 through 48) and its
corresponding network (ENETs 1 through 4) are displayed via the
Repeater Statistics screen shown in
Figure 5-32 .
To access the Repeater Statistics screen, use the arrow keys to highlight
the REPEATER STATISTICS menu item on the Device Statistics
Menu screen and press ENTER. The Repeater Statistics screen displays.
Figure 5-32 Repeater Statistics Screen for Repeater Ports (1 – 48)
Firmware Revision: XX.XX.XX
Repeater Statistics
22511-29
Device Name: 2E43-51
BOOTPROM Revision: XX.XX.XX
RETURN CLEAR COUNTERS EXIT
2E43-51 LOCAL MANAGEMENT
Event Message Line
PORT #: nn
Bytes Received:
Frames received:
Total Errors:
Collisions:
OOW Collisions:
CRC Errors:
Alignment Errors:
Undersize Packets:
Oversize Packets
Broadcasts
Multicasts:
Link Status:
Admin Status:
Network #: xx
7500456
6789
0
0
0
0
0
0
0
0
0
Link
Enabled
Port #: xx
7500456
6789
0
0
0
0
0
0
0
0
0
No Link
Disabled
