Chapter 5: Local Management
5-66 2E43-51/2E43-51R User’s Guide
Figure 5-27 Port Level Security Configuration Screen
The following section defines the fields on the Port Level Security
Configuration screen.
Port (Read-only)
Indicates the repeater port on the ENET connector (ENET 1 through 4)
selected in the INTERFACE # field. Refer to
Table 5-5 for the
connector/repeater port relationship on the device.
Table 5-5 ENET/Repeater Port Relationship
State (Selectable)
Used to select the state of security for frames received by any port on the
connector. The states are as follows:
• Secure – Allows the ports on the connector to receive only those
frames with the address as determined by the selection in the
Lock/Learn field.
ENET 1 = Repeater ports 1 – 12 ENET 3 = Repeater ports 25 – 36
ENET 2 = Repeater ports 13 – 24 ENET 4 = Repeater ports 37 – 48
2E43-51 LOCAL MANAGEMENT
Port Level Security Configuration
Module Type: 2E43-51 Firmware Revision: XX.XX.XX
BOOTPROM Revision: XX.XX.XX
Po rt State Lock/Learn Action On Intruder Secure Address
1 [Secure] [LockOnNext] [DisablePort] [SendTrap]
2 [NonSecure] [ Unlocked] [00-00-00-00-00-00]
3 [Secure] [LockedOnAddr] [DisablePort] [SendTrap] [xx.xx.xx.xx.xx.xx]
4 [NonSecure] [Unlocked] [00-00-00-00-00-00]
5 [NonSecure] [Unlocked] [00-00-00-00-00-00]
6 [NonSecure] [Unlocked] [00-00-00-00-00-00]
7 [NonSecure] [Unlocked] [00-00-00-00-00-00]
8 [NonSecure] [Unlocked] [00-00-00-00-00-00]
9 [NonSecure] [Unlocked] [00-00-00-00-00-00]
10 [NonSecure] [Unlocked] [00-00-00-00-00-00]
11 [NonSecure] [Unlocked] [00-00-00-00-00-00]
12 [NonSecure] [Unlocked] [00-00-00-00-00-00]
INTERFACE #: [1] SAVE EXIT RETURN
Event Message Line
2251_113
