Chapter 5: Local Management
5-62 2E43-51/2E43-51R User’s Guide
PORT LEVEL SECURITY CONFIGURATION
Used to set the security for each port of a connector, individually. For
details, refer to
Section 5.20 .
5.19 REPEATER LEVEL SECURITY CONFIGURATION
The Repeater Level Security Configuration screen, Figure 5-26 , is used to
set the state of security for all ports on a connector. A connector can be set
to receive all frames (NonSecure state), lock on the source address of the
next frame received (LockOnNext), or lock on the source address of the
last frame received (LockedOnAddr). When either of the last two options
are set, the switch can be set to receive or not receive frames and to send
or not send traps when an intruder is detected.
To access the Repeater Level Security Configuration screen, use the arrow
keys to highlight the REPEATER LEVEL SECURITY
CONFIGURATION menu item on the Repeater Configuration Menu
screen and press ENTER. The Repeater Level Security Configuration
screen displays.
Figure 5-26 Repeater Level Security Configuration Screen
2E43-51 LOCAL MANAGEMENT
Repeater Level Security Configuration
Module Type: 2E43-51 Firmware Revision: XX.XX.XX
BOOTPROM Revision: XX.XX.XX
Interface State Lock/Learn Action On Intruder
1 [Secure] [LockOnNext] [DisablePort] [SendTrap]
2 [Secure] [LockOnNext] [DisablePort] [SendTrap]
3 [Secure] [LockedOnAddr] [DisablePort] [SendTrap]
4 [NonSecure]
SAVE EXIT RETURN
