Chapter 5: Local Management
5-36 2E43-51/2E43-51R User’s Guide
5.10 SWITCH CONFIGURATION SCREEN
The Switch Configuration screen, Figure 5-17 , provides the basic setup
options to make a switch operational in your network.
To access the Switch Configuration screen from the Device Configuration
Menu screen, use the arrow keys to highlight the SWITCH
CONFIGURATION menu item and press ENTER. The Switch
Configuration screen displays showing up to 7 ports, depending on if
there are Fast Ethernet Interface Modules and an HSIM installed in the
device.
Figure 5-17 Switch Configuration Screen
NOTE
The Switch Configuration screen is not available if the
operational mode of the device is set to SECURE FAST VLAN.
This screen may only be used when the device is configured to
operate as an 802.1D or 802.1Q switch.
Firmware Revision: XX.XX.XX
Switch Configuration
22511-18
Device Name: 2E43-51
BOOTPROM Revision: XX.XX.XX
Port #
1
2
3
4
5
6
7
State
learning
listening
standby
learning
listening
standby
listening
2E43-51 LOCAL MANAGEMENT
Event Message Line
RETURN SAVE
MAC Address
00-00-1D-00-00-00
00-00-1D-00-00-01
00-00-1D-00-00-02
00-00-1D-00-00-03
00-00-1D-00-00-04
00-00-1D-00-00-05
00-00-1D-00-00-06
Status
[ENABLED]
[DISABLED]
[ENABLED]
[DISABLED]
[ENABLED]
[DISABLED]
[ENABLED]
Switch Address: 00-00-1D-00-00-00
Number of Ports: 7 Type of STA: [DEC]
Age Time (sec): 300
EXIT
