Repeater Configuration Menu Screen
2E43-51/2E43-51R User’s Guide 5-61
5.18 REPEATER CONFIGURATION MENU SCREEN
The Repeater Configuration Menu screen, Figure 5-25 , is used to access
the Repeater Level Security Configuration, or Port Level Security
Configuration screen. To access the Repeater Configuration Menu screen
from the Device Specific Configuration Menu screen, select the
REPEATER CONFIGURATION MENU item and press ENTER. The
Repeater Configuration Menu screen displays.
Figure 5-25 Repeater Configuration Menu Screen
The following introduces each screen that is accessible from the Repeater
Configuration Menu.
REPEATER LEVEL SECURITY CONFIGURATION
Used to set the state of security for each port of a connector
simultaneously. The ports can be set to receive all frames (NonSecure
state), lock on the source address of the next frame received
(LockOnNext) or lock on the address of the last frame received
(LockedOnAddr). For details, refer to
Section 5.19 .
Firmware Revision: XX.XX.XX
Repeater Configuration Menu
REPEATER LEVEL SECURITY CONFIGURATION
PORT LEVEL SECURITY CONFIGURATION
2251_104
BOOTPROM Revision: XX.XX.XX
Module Type: 2E43-51
2E43-51 LOCAL MANAGEMENT
RETURN EXIT
