Using the RESET Button
2E43-51/2E43-51R User’s Guide 4-7
4.4 USING THE RESET BUTTON
The RESET button shown in Figure 4-3 resets the 2E43-51 processor
without affecting the NVRAM.
Figure 4-3 RESET Button
To reset the 2E43-51 processor, press and release the RESET button. The
2E43-51 goes through a reset process for approximately 45 seconds.
!
CAUTION
Pressing the RESET button resets the device, and all current
switching being performed by the device is halted. A network
downtime of up to two minutes will result from this action.
LINK 1
LINK 1
ENET 1
ENET 3
E3
E1
E4
E2
2E43-51
COM
PWR
CPU RESET
RESET Button
2251-37
