Installing Optional Fast Ethernet Interface Modules
2E43-51/2E43-51R User’s Guide C-7
C.3 INSTALLING OPTIONAL FAST ETHERNET
INTERFACE MODULES
Figure C-3 shows the locations of the Fast Ethernet Interface Module
connectors on for ports 5 and 6 and the High Speed Interface Module for
port 7.
Figure C-3 Fast Ethernet Interface Module Connector Location
2251-11
Optional Fast Ethernet
Interface Modules
Connectors
FRONT PANEL
TOP VIEW WITHOUT COVER
Optional HSIM is installed
above the optional Fast
Ethernet Interface Modules
Connector
Optional interface
modules on HSIM FRONT PANEL
Redundant
Power
Supply
(2E43-51R
only) Primary
Power
Supply
Redundant
Power
Supply
(2E43-51R
only) Primary
Power
Supply
