FE-100TX LED
2E43-51/2E43-51R User’s Guide
4-5
Table 4-3
10/100 LED Indications When RX LED Is Off
NOTE
No link exists if the associated port (5 or 6) RX LED is off.
LED
Color
Indication
10/100
Off
No Link or no cable attached. FE-100TX
forced to 10 Mbps operation, or is
manually set to “auto-negotiate” mode.
Green
No Link or no cable attached. FE-100TX is
forced to 100 Mbps operation.
