Chapter 5: Local Management
5-30 2E43-51/2E43-51R User’s Guide
Figure 5-14 Clear NVRAM Warning Screen
5. Select YES and the message “CLEARING NVRAM. REBOOT IN
PROGRESS...” displays.
6. The 2E43-51 clears NVRAM and reboots. All user-entered parameters
default to factory default settings.
5.7.12 Enabling/Disabling IP Fragmentation
To enable or disable IP Fragmentation, proceed as follows:
1. Use the arrow keys to highlight the IP Fragmentation field.
2. Press the SPACE bar to choose either ENABLED or DISABLED.
3. Use the arrow keys to highlight the SAVE command.
4. Press ENTER. The message “SAVED OK” displays at the top of the
screen.
!
CAUTION
If the 2E43-51 is being bridged to an FDDI ring (for example,
via an optional HSIM-F6), enable IP Fragmentation. If it is
disabled, all FDDI frames that exceed the maximum Ethernet
frame size are discarded.
WARNING
174251
YOU HAVE ELECTED TO CLEAR NVRAM. THIS WILL CLEAR
ALL SYSTEM DEFAULTS INCLUDING BUT NOT LIMITED TO
IP ADDRESS, INTERFACE CONFIGURATION, AND COM PORT
CONFIGURATION, THEN RESET THE BOARD.
ARE YOU SURE YOU WANT TO CLEAR NVRAM?
YES NO
