Switch Statistics Screen
2E43-51/2E43-51R User’s Guide 5-71
REPEATER STATISTICS
The Repeater Statistics screen provides the operating statistics for each
port (1 through 48) and its corresponding network (ENETs 1 through 4).
For details, refer to
Section 5.25 .
5.22 SWITCH STATISTICS SCREEN
The Switch Statistics screen, Figure 5-29 , lists the number of frames
received, transmitted, filtered, and forwarded by each port.
To access the Switch Statistics screen from the Device Statistics Menu
screen, use the arrow keys to highlight the SWITCH STATISTICS
menu item and press ENTER. The Switch Statistics screen displays.
Figure 5-29 Switch Statistics Screen
Firmware Revision: XX.XX.XX
Switch Statistics
22512-26
Device Name: 2E43-51
BOOTPROM Revision: XX.XX.XX
RETURN
2E43-51 LOCAL MANAGEMENT
Event Message Line
Port #
1
2
3
4
5
6
7
Frames Rcvd
100
100
100
100
100
100
100
Frames Txmtd
100
100
100
100
100
100
100
Frames Fltrd
0
0
0
0
0
0
0
Frames Frwded
100
100
100
100
100
100
100
CLEAR COUNTERS EXIT
