Chapter 5: Local Management
5-70 2E43-51/2E43-51R User’s Guide
To access the Device Statistics Menu from the Device Menu screen, use
the arrow keys to highlight the DEVICE STATISTICS menu item and
press ENTER. The Device Statistics Menu
screen displays.
Figure 5-28 Device Statistics Menu Screen
The Device Statistics Menu screen displays the following menu items:
SWITCH STATISTICS
The Switch Statistics screen lists the number of frames received,
transmitted, filtered, and forwarded by each interface. For details, refer to
Section 5.22 .
INTERFACE STATISTICS
The Interface Statistics screen provides the MIB-II statistics for each
switched interface, on an interface-by-interface basis. For details, refer to
Section 5.23 .
RMON STATISTICS
The RMON Statistics screen displays all the statistics gathered by the
embedded RMON agent built-in to the 2E43-51. For details, refer to
Section 5.24 .
Firmware Revision: XX.XX.XX
Device Statistics Menu
SWITCH STATISTICS
INTERFACE STATISTICS
RMON STATISTICS
REPEATER STATISTICS
22512-67
Device Name: 2E43-51
BOOTPROM Revision: XX.XX.XX
2E43-51 LOCAL MANAGEMENT
EXIT RETURN
