Innovation Series Water Heaters Chapter 8
OMM-0079_0B USER MANUAL RS232 Communication
Page 88 of 200 AERCO International, Inc.
· 100 Oritani Dr. · Blauvelt, NY 10913 · Ph.: 800-526-0288
07/21/11
NOTE
The Level 1 password (159) must be entered to change options in the Setup,
Configuration and Tuning Menus. The Level 2 password (6817) must be entered to view
or change options in the Calibration and Diagnostics Menus.
With the exception of the password entry, all other keyboard entries can be made using
either upper or lower case.
5. To view the available menus in the top-down sequence shown in Figure 3-2, enter M >. The
Menu title and first 10 options will be displayed.
6. When viewing menus containing more than 10 options, enter N to display the remaining
options.
7. Shortcut keys are also available to go directly to a specific menu. These shortcut keys are:
m0
Default (Operating) Menu
m1 Setup Menu
m2 Configuration Menu
m3 Tuning Menu
m4 Calibration Menu
m5 Diagnostic Menu
8. To change a value or setting for a displayed menu option, proceed as follows:
(d) Enter C, followed by the number to the right of the displayed option to be changed, and then
press .
Enter the desired value or setting for the option and press . Refer to Chapter 3, Tables 3-2
through 3-5 for allowable entry ranges and settings for the Operating, Setup, Configuration and
Tuning Menus. (The Calibration and Diagnostic Menus should only be used by Factory-Trained
service personnel).
Menu changes will be stored in non-volatile memory.
9. To redisplay the menu and view the option which was just changed in step 5, enter D and press
.
10. To display the Fault (F) Log, Sensor (S) Log or Time (T) Line Log, press F, S or T followed by .
Refer to paragraph 9.4 for descriptions and samples of these data logs.
11. To log off and terminate the RS232 com-munication link, press L followed by .
8.4 DATA LOGGING
During operation, the C-More Control Panel continuously monitors and logs data associated with
operational events, faults and sensor readings associated with the water heater system. Descriptions of
these data logs are provided in the following paragraphs. The basic procedure for accessing each data
log is described in paragraph 9.3, step 7.
8.4.1 Fault Log
The C-More Control Panel logs the last 10 faults (0 – 9) starting with the most recent (#0). They can be
viewed in the front panel display or via the RS232 port. The Fault Log cannot be cleared. If the Fault Log
already contains 10 faults, the earliest fault is overwritten when a new fault occurs. A sample Fault Log
display is shown in Table 8-1.
