AERCO Innovation (G-10-1350 to G-11-0563) - Manual (Page 103)

Appendix E Innovation Series Water Heaters
GF-128
Parts Lists Drawings USER MANUAL OMM-0079_0B
07/21/11 AERCO International, Inc.
· 100 Oritani Dr. · Blauvelt, NY 10913 · Ph: 800-526-0288
Page 103 of 200
APPENDIX E: PARTS LIST DRAWINGS
79.25 in.
[2013.0 mm]
28.00 in.
[711.2 mm]
14.23 in.
361.4 mm
44.64 in.
[1133.9 mm]
24.18 in.
[614.2 mm]
22.89 in.
[581.4]
44.63 in.
[1133.6 mm]
Ø 6.00 Iin.
[152.4 mm]
FLUE CONN.
23.00 in.
[584.2 mm]
9.08 in.
[584.2 mm]
33.75 in.
[857.3 mm]
Ø 0.75 in.
[191.1 mm]
54.83 in.
[1392.6 mm]
5.16 in.
[131.1 mm]
R 23.00 in.
[584.2 mm]
FRONT DOOR
CLEARANCE
