ALTERNATOR

TNV IDI Service Manual

11-7

Dynamo Specifications

DYNAMO SPECIFICATIONS

Yanmar Part Number

119910-77200

Nominal Output

20 Amps

Weight

3.97 lb (1.8 kg)

Revolution Direction (As Viewed From Pulley)

Clockwise

Rating

Continuous

Battery Voltage

12 Volts

Rated Revolution

3500 rpm

Operating Range

1400 - 6600 rpm

Grounding Characteristics

Negative (-) Side of Circuit

Regulator

Current Limiter (Part No. 119653-77710)

Outside Diameter of Pulley

A-Belt

2.56 in. (65 mm)

Special M-Belt

2.28 in. (58 mm)

Belt Shape

Type A or Type Special M
