TNV IDI Service Manual 9-1
TNV IDI Service Manual Section 9
LUBRICATION
SYSTEM
Page
Before You Begin Servicing ............................................................ 9-3
Introduction...................................................................................... 9-5
Oil Pump Service Information.......................................................... 9-5
Engine Oil Pressure................................................................... 9-5
Outer Rotor Outside Clearance ................................................. 9-5
Outer Rotor Side Clearance ...................................................... 9-5
Outer Rotor to Inner Rotor Tip Clearance ................................. 9-5
Inner Rotor and Gear Boss Clearance ...................................... 9-6
Lubrication System Diagram ........................................................... 9-7
Checking Engine Oil Pressure ........................................................ 9-8
Trochoid Oil Pump........................................................................... 9-8
Oil Pump Components .............................................................. 9-8
Disassembly of Oil Pump .......................................................... 9-9
Cleaning and Inspection .......................................................... 9-10
Reassembly of Oil Pump ......................................................... 9-11
