STARTER MOTOR
TNV IDI Service Manual 10-5
Introduction
INTRODUCTION
This section of the Service Manual covers the servicing of starter motor. Yanmar Part No. 119717-77010 is
used in this section to show the service procedures for a representative starter motor. For specific part
detail, see the Yanmar Parts Catalog for the engine being serviced.
STARTER MOTOR INFORMATION
YANMAR
Part
Number
Mfg.
Mfg.
Model
Number
Specification
No Load Loaded
Terminal
Voltage
Amperage
Draw
RPM
Terminal
Voltage
Amperage
Draw
Torque RPM
119515-
77010
Denso
428000-
2190
DC12V -1.3 hp
(1.0 kW)
11.5 90A (Max)
3000
(Min)
8.0 200 (Max)
42 in.-lb
(4.7 N·m;
0.48 kgf·m)
1240
(Min)
119717-
77010
Denso
428000-
1590
DC12V -1.5 hp
(1.1 kW)
11.5 90A (Max)
3000
(Min)
8.7 230 (Max)
61 in.-lb
(6.9 N·m;
0.70 kgf·m)
1130
(Min)
119740-
77010
Denso
428000-
3310
DC12V -1.9 hp
(1.4 kW)
11.5 90A (Max)
3000
(Min)
8.5 350 (Max)
119 in.-lb
(13.5 N·m;
1.38 kgf·m)
1000
(Min)
