Page 112
ENGINE
TNV IDI Service Manual
6-13
Cylinder Block Specifications
CYLINDER BLOCK SPECIFICATIONS
Cylinder Block
Inspection Item
Model
Standard
Limit
Reference
Page
Cylinder Inside Diameter
3TNV72
2.8346 - 2.8358 in.
(72.000 - 72.030 mm)
2.7638 in.
(70.200 mm)
See
Inspection of
Cylinder
Block on
page 6-47
Cylinder Bore
Roundness
0.0004 in. (0.01 mm)
or less
0.0012 in.
(0.03 mm)
Taper
