Class of Service Configuration 9145E NID Software User’s Manual
Classifier Mapping
91
those CoSQs will be changed. Once all classification mapping are set, press Esc to return to the Classifier
Mapping screen.
Figure 10-3 Ingress Tagged Packet Classifier Screen
10.2.2 Untagged Packet Classifier Mode
There are three classification modes for untagged packets: IP Precedence Mode, DSCP Mode and AFEF
Mode. The customer selects the mode for untagged packets by typing
3 on the Classifier Mapping screen
(Figure 10-2) and pressing Enter. The mode will be highlighted. Use the Space Bar to cycle through the IP
Precedence, DSCP, and AFEF selections. Once you have selected the desired mode, press the Space
Bar to set your choice.
10.2.3 Untagged Packet Classifier Mapping
To configure the queue mapping for untagged packets, type 2 and press Enter. One of the Untagged
Packet Classifier Mapping screens (Figure 10-4 through Figure 10-5) opens, depending which mode you
selected in paragraph 10.2.2.
Canoga Perki ns Corp. Ethernet Network Interface Devi ce 04-SEP-2008
M odel 9145E-101-2-0 V02.10 F121 02:59:35
---------------INGRESS TAGGED PACKET CLASSIF IER M APPING---------------
PCP CoS Q
--- ----
0 LLQ
1 LLQ
2 Q3
3 Q3
4 Q1
5 Q1
6 Q1
7 Q1
Select PCP or a Range x-y [0-7]:
------------------------------------M essages------------------------------------
