System Configuration
9145E NID Software User’s Manual
IP/SNMP Agent Configuration
11
Figure 3-3 Management IP configuration Menu
NOTE: The Test IP is used for PM and SAM testing. If PM and SAM are not licensed,
the Test IP address can not be entered.
5. Test IP Address - Used to set the IP Address for PM and SAM optional applications.
Test Subnet Mask - Used to set the Subnet Mask for PM and SAM optional applications.
6. Test Port - Used to select which port(s) allow access to the Test IP address. Parameters include:
Both User and Net Ports, Net Port Only, User Port Only, or No Ports Allowed.
7. Telnet Security - Used to enable or disable checking if the host initiating the Telnet session is listed
in the host table. If Telnet Security is enabled the host must be included as part of the host table.
Default is disabled, which allows access from all hosts.
8. Reply to Broadcast Ping - Use to enable or disable the 9145E to reply to ICMP packets with a
broadcast IP Host Address in the Manager IP subnet. Broadcast Ping replies are an ICMP packet and
are rate limited to 100pps. Default is disabled.
Canoga Perkins Corp. Ethernet Network Interface Device 12-SEP-2008
Model 9145E-101-2-0 V02.10 F121 19:14:27
------------------------MANAGEMENT IP CONFIGURATION-----------------
In-band Manager MAC Address 00 40 2A 01 D9 A0
Manager MAC Address (In-band) 00 40 2A 01 D9 A0
Manager Port Status UP
Subnet Mask 255.255.000.000
Default Gateway 172.016.001.001
2) Manager Port Both User and Net Ports
3) Manager VLAN Tagging Disabled
4) Manager VLAN ID 0
5) Test IP Address 000.000.000.000
Test Subnet Mask 255.255.255.000
6) Test Port Both User and Net Ports
7) Telnet Security Disabled
8) Reply to Broadcast Ping Disabled
Select [1-8]:
-----------------------------------Messages-------------------------
