System Configuration 9145E NID Software User’s Manual
IP/SNMP Agent Configuration
17
Figure 3-10 V2c-Inform Notification Type Parameter
• If V3-Trap was selected (Figure 3-11):
a. Use the Space Bar to select the Security Name and press Enter.
b. Use the Space Bar to select the Security Level (No Auth/No Priv, Auth/No Priv, or Auth/Priv)
and press Enter.
c. Press Esc to return to the Trap Table menu (Figure 3-7).
Figure 3-11 V3-Trap Notification Type Parameter
4. If V3-Inform was selected (Figure 3-13):
a. Type in the Security Name and press Enter.
b. Type in the SNMP Engine ID and press Enter.
c. Cycle through the Authentication Protocol setting (MD5, SHA, or None) using the Space
Bar. Press Enter to accept the setting.
Canoga Perkins Corp. Ethernet Network Interface Device 12-SEP-2008
Model 9145E-101-2-0 V02.10 F121 00:35:00
----------------------------------EDIT TRAP/NOTIFICATION TYPE-----------------------
IP Address : 172.002.015.032
Trap/Notification Port : 125
Notification Type : V2c-Inform
1. Community Name :Private
2. Retries : 5
3. Timeout in Seconds : 30
Select [1-3]:
---------------------------------------------Messages----------------------------------------------
Can og a Perki ns Co rp. E th ern et N etw o rk In terface D evi ce 12 -SE P-20 08
M od el 9 1 45 E-10 1-2-0 V 0 2.10 F12 1 19: 12: 37
----------------------------------E D IT T RA P/N O T IFICA T IO N T Y PE -------------------
IP A d dress : 17 2.00 2.1 45 .0 11
T rap /N otification Port : 1 62
N ot ificatio n T yp e : V 3 -T rap
1. Security N ame : ad min
2. Security L evel : N o A u th/ No Pri v
------------------------------------M ess ages------------------------------------
