Diagnostics 9145E NID Software User’s Manual
35
4.0 Diagnostic Functions
From the Main menu (Figure 2-3), select (2) Diagnostics menu. The Diagnostics menu (Figure 4-1) opens.
The Diagnostics functions to set up loopback, VLAN loopback, latency and jitter testing, cable diagnostics,
and PING tests, are configured and initiated here. The following paragraphs describe each item on the
Diagnostics menu.
Figure 4-1 Diagnostics Menu
NOTE: If you enter 6 and the unit is not licensed for PM or SAM, access will
be denied.
Canoga Perkins Corp. Ethernet Network Interface Device 22-SEP-2008
Model 9145E-101-2-0 V02.10 F121 02:59:35
------------------------------------------DIAGNOSTICS-----------------------------------------
1)
Loopback Setup
2) Latency/Jitter Test
3) PING Generation
4) VLAN Loopback
5) Cable Diagnostics
6) Network Performance
Select [1-6]:
----------------------------------------------Messages---------------------------------------------
Chapter 4
Diagnostics
