802.3AH OAM 9145E NID Software User’s Manual
OAM Statistics
83
Figure 9-3 The OAM Peer Information Screen
9.3 OAM Statistics
The OAM Statistics screen provides the customer with information concerning OAMPDUs, Event
Notifications, Loopback Requests, Variable Requests and Responses, and Unsupported Opcodes. From
the OAM Control screen. Type
3 and press Enter The OAM Statistics screen (Figure 9-4) opens. Press
Esc to return to the 802.3AH OAM menu.
Canoga Perkins Corp. Ethernet Network Interface Device 04-SEP-2008
Model 9145E-101-2-0 V02.10 F121 02:59:35
-----------------------------------OAM PEER INFORMATION-------------------------
User Port Peer Extension Port Peer
OAM Peer Status
Inactive Inactive
OAM Peer MAC Address Unavailable Unavailable
OAM Peer Vendor OUI Unavailable Unavailable
OAM Peer Vendor Info (Hex) Unavailable Unavailable
OAM Peer Mode Unknown Unknown
OAM Peer Max PDU Size Unavailable Unavailable
OAM Peer Config Revision Unavailable Unavailable
OAM Peer Functions Supported Unavailable Unavailable
:------------------------------------Messages------------------------------------
