9145E NID Software User’s Manual Port Information
Layer 2 Statistics
56
5.3 Layer 2 Statistics
To view Layer 2 statistics, select Layer 2 Statistics (3) from the Port Information screen (Figure 5-1) and
press Enter. The Layer 2 Statistics screen (Figure 5-12) opens.
Use the controls as listed to view the Layer 2 Statistics screen. Press Esc to return to the Port Information
screen.
Figure 5-12 Layer 2 Statistics Screen
Change Counter Frame Size - The 9145E has a programmable counter for frames greater than the
programmed size. Type C and press Enter. Type in the desired frame size, between 64 and 10,000,
and press Enter to accept change.
Error Counters - Type E and press Enter to view the Layer 2 Error Statistics screen (Figure 5-13).
Frame Type Counters - Type T and press Enter to view the Layer 2 Frame Type Statistics screen
(Figure 5-14).
Raw Counters - These are the total counters since the last time the 9145E was reset. Press Ctrl+T to
view raw layer 2 statistics.
Reset Counters - Press Ctrl+R to reset the counters. The counters are reset independently of the
raw counters. The raw counters can not be cleared.
Frame Counters - Press F (available on Layer 2 Error Statistics and Layer 2 Frame Type Statistics
menus) to return to the Layer 2 Statistics screen.
Canoga Perki ns Corp. Ethernet Net work Interface Device 22-SEP-2008
Model 9145E-101-2-0 V02.10 F121 02: 59: 35
-- -- --- -- --- --- -- --- -- --- -L AYE R 2 S TAT IS TIC S (CU RRE NT )-- -- --- -- --- --- -- --- -- --
Us er Por t Ne t Por t
L in k S ta te UP UP
S pe ed/ Du ple x 10 0M/ FUL L 1 000 M/ FUL L
F ra mes S ent 2 136 5 276 03 597 3
F ra mes R cvd 555 233 9 270 50 263 5
B yt es Se nt 272 401 3 13 61 529 61 582 1
B yt es Rc vd 41 495 676 6 13 61 119 57 947 0
F ra mes > 15 18 0 230 88 958 3
F ra mes > 15 22 0 230 78 069 1
L in e R at e U til iz ati on 0% 0%
L as t C ou nte r R es et: 8 da ys 00 :36 :3 5
Se lec t [(C ) Cha ng e C oun te r F ra me Si ze, (E ) Err or Co un ter s,
(T ) F ra me Typ e Cou nt ers , (CT RL- T) Ra w Cou nt ers , ( CT RL- R) Re se t C oun te rs] :
-- -- --- -- --- --- -- --- -- --- -- --- --- -- -Me ss age s- --- --- -- --- -- --- -- --- --- -- --- -- --
