9145E NID Software User’s Manual Class of Service Configuration
Classifier Mapping
92
10.2.3.1 IP Precedence Mode
Type the number of the IP Precedence, or a series of numbers such as 3-7 if desired, and press Enter.
The CoSQ setting in the column beside the IP Precedence number, or the first number/value of the series
(for example: 3 if 3 - 7) is highlighted. Use the
Space Bar to scroll through the available queues. Select a
queue and press Enter. If a series of numbers was chosen, all of those CoSQs will be changed. Once all
CoSQs are set, press Esc to return to the Classifier Mapping screen.
Figure 10-4 Ingress Untagged Packet Classifier Mapping Screen - IP Precedence Mode
Canoga Perki ns Corp. Ethernet Network Interface Devi ce 04-SEP-2008
Model 9145E-101-2-0 V02.10 F121 02:59:35
--------------INGRESS UNTAGGED PACKET CLAS SIFIER MAP PING--------------
IP Precedence Mode
IP Precedence CoSQ
------------- ----
0 Q1
1 Q1
2 Q2
3 Q2
4 Q3
5 Q3
6 LLQ
7 LLQ
Select IPP or a Range x-y [0-7]:
:------------------------------------Messages------------------------------------
