System Alarms & Logs 9145E NID Software User’s Manual
63
6.0 System Alarms
Use the System Alarms Screen to view alarms and faults on the 9145E.
To view alarm status, select System Alarms ( 4) from the Main Menu and press Enter. The System Alarms
Screen (Figure 6-1) opens. Press Esc to return to the Main Menu.
Figure 6-1 System Alarm Screen
Canoga Perkins Corp. Ethernet Network Interface Device 04-SEP-2008
Model 9145E-101-2-0 V02.10 F121 02:59:35
-------------------------------------SYSTEM ALARMS------------------------------
Link
Remote Fault SFP Transmitter
User Port *** Down *** N/A N/A
Network Port Disabled N/A N/A
MGMT UTP Port Disabled
Link
Loss Fwd User->Net No
Link Loss Fwd Net->User Yes
AC Power Supply A Status Bad 5.07 Volts Output (5.10 < OK > 5.40)
AC Power Supply B Status Bad 4.77 Volts Output (5.10 < OK > 5.40)
Main Board Voltages
One or more mainboard voltages are BAD..
Fan Status Both Fans BAD
Temperature Status OK 34.0C (0.0C < OK < 70.0C)
Hit 'ESC' to return to previous menu
------------------------------------Messages------------------------------------
