9145E NID Software User’s Manual 802.3AH OAM
OAM Peer Information
82
Figure 9-2 The OAM Control Screen
9.2 OAM Peer Information
This table contains information about the OAM peer for a particular Ethernet-like interface. OAM entities
communicate with a single OAM peer entity on Ethernet links on which OA is enabled and operating
properly. There is one entry in this table for each port for which information on the peer OAM entity is
available.
The OAM Peer Information screen provides information about OAM Peer Status, OAM Peer MAC
Address, OAM Peer Vendor, OAM Peer Vendor Info (Hex), OAM Peer Mode, OAM Peer Max PDU Size,
OAM Peer Config Revision, and AM Peer Functions Supported.
From the OAM Control screen, select OAM Peer Information ( 2) and press Enter. The OAM Peer
Information screen (Figure 9-3) opens. Press Esc to return to the 802.3AH OAM menu.
Canoga Perki ns Corp. Ethernet Network Interface Devi ce 04-SEP-2008
Model 9145E-101-2-0 V02.10 F121 02:59:35
----------------------------------------OAM CONTROL-----------------------------
User Port Network Port
--------- --------------
OAM Operational Status Link Fault Di sabled
OAM Max PDU Size 1518 1518
OAM Revisi on 1 1
OAM Functi ons S upported Unidirectional Unidirectional
Loopback Loopback
Link Events Link Event s
OAM Loopback Status
No Loopback No Loopback
OAM Remot e Link Fault No No
1) OAM Admin State
Enabled Di sabled
2) OAM Mode Active Acti ve
3) OAM Loopback Command No Loopback No Loopback
4) Process Rx Loopback OAMPDU No No
5) Process Rx Link Fault Flag Yes Yes
6) Fwd Critical Event No No
Select [1-6]:
:------------------------------------Messages------------------------------------
