Kontron Carrier Grade Server TIGW1U
December 2009 Product Guide, rev. 1.3
85
Troubleshooting—TIGW1U server
In addition to the beep codes above, additional beep codes are provided if an Intel ®
Remote Management Module (Intel ® RMM) is installed. The RMM provides the following
additional beep codes.
Table 10. POST Error Beep Codes
Number of Beeps Reason for the beeps and action to take
1, 2, or 3 Memory error. Reseat the memory or replace the DIMMs with known good modules.
4 – 7 or 9 – 11
Fatal error indicating a possible serious system problem. Remove all add-in cards and
re-start the system. If the error still occurs, contact your system manufacturer. If the
beep codes are not generated after the add-in cards are removed, insert the cards one
at a time, booting the system between each card addition, until the beeps again occur
to reveal the malfunctioning card.
8
Replace or reseat the system video add-in card. If on-board video is bing used, the
server board may be faulty.
Table 11. Error Beep Codes Provided by an Intel ® Remote Management Module 2
Beep Code Reason for the beeps and action to take
1 Control panel CMOS clear has been initiated.
1-5-1-1 Processor failure. Reseat or replace the failed processor.
1-5-2-1
No processor is installed or the CPU 1 socket is empty. Reseat or replace the failed
processor.
1-5-2-3
Processor configuration error or CPU 1 socket is empty. Reseat or replace the failed
processor. In a two-processor system, make sure the processors are identical.
1-5-2-4 Front-side bus select configuration error.
1-5-4-2 DC power unexpectedly lost.
1-5-4-3 Chipset control failure.
1-5-4-4 Power control failure.
