Kontron microETXexpress-PV User’s Guide
76
Feature Option Description
3E8/IRQ4
2E8/IRQ3
Serial Port2
Mode SPP
IrDA
ASK IR
Serial Port2 mode selection
(depends on the carrier
board support. Normally
only SPP is present on the
carrier)
IR I/O Pin
Select SINB/SOUTB
IRRX/IRTX
Allows BIOS to select
receive or transmit pin for
Serial Port2 (IR Mode).
This only shows if “Serial
Port2 Mode” is set to “IrDA”
or “ASK IR”.
IR Duplex Mode Full
Duplex
Half
Duplex
Allows BIOS to select full
or half duplex for Serial
Port2 (IR Mode)
This only shows if “Serial
Port2 Mode” is set to “IrDA”
or “ASK IR”.
ACPI Configuration
Feature Option Description
General ACPI
Configuration Submenu Allows configuration of
the general ACPI features
Advanced ACPI Submenu Allows configuration of
the advanced ACPI features
