Kontron microETXexpress-PV User’s Guide
36
NOTE: This connector is for development debug purposes only. The XDP
connector pin-out is under NDA.
4.1.5 Connector J5 –JTAG
This is the Intel® ICH8M debug connector.
WARNING : The debug port is for internal use only. Do not connect any devices.
Table 10: J5 JTAG Connector Pin-Out
Pin Name Termination
1 V_3V3_S5 -
2 CPLD_TDI PU to 3.3V SUS of 1K.
3 CPLD_TCK PD to 1K.
4 CPLD_TMS PU to 3.3V SUS of 1K.
5 CPLD_TDO PU to 3.3V SUS of 1K.
6 GND -
7 KILL_POWER_UP# PU 5K to 25K in the
CPLD.
8 GND -
4.1.6 SSD Mezzanine Connector
The optional onboard SSD module interface uses SATA to connect to port 2 the
Intel® ICH8M.
Table 11: J6 SSD Connector Pin-Out
Pin Name
1 GND
2 GND
3 GND
4 SATA_RX+
5 V_3V3
6 SATA_RX-
7 V_3V3
8 GND
9 V_3V3
10 SATA_TX+
11 NC
12 SATA_TX-
13 RESET
14 GND
