Kontron microETXexpress-PV User’s Guide
24
Pin Signal Description Type Terminati
on
Comment
Data+
B65 PCIE_RX1- PCIe 1 Receive
Data-
- -
B66 WAKE0# PCI Express Wake
Event
I-3.3 SUS
PU 3.3
SUS of
10K Connected to
ICH8M pin WAKE
B67 WAKE1# General Purpose
Wake Event
I-3.3 SUS
PU 3.3
SUS of
10K Connected to
ICH8M pin RI#
B68 PCIE_RX0+ PCIe 0 Receive
Data+
DP-I
- -
B69 PCIE_RX0- PCIe 0 Receive
Data- - -
B70 GND (Fixed) Power Ground PWR - -
B71 LVDS_B0+ LVDS Display
Channel B0
(Positive)
Not
connected
nc nc
B72 LVDS_B0- LVDS Display
Channel B0
(Negative)
Not
connected
nc nc
B73 LVDS_B1+ LVDS Display
Channel B1
(Positive)
Not
connected
nc nc
B74 LVDS_B1- LVDS Display
Channel B1
(Negative)
Not
connected
nc nc
B75 LVDS_B2+ LVDS Display
Channel B
2(Positive)
Not
connected
nc nc
B76 LVDS_B2- LVDS Display
Channel B2
(Negative)
Not
connected
nc nc
B77 LVDS_B3+ LVDS Display
Channel B3
(Positive)
Not
connected
nc nc
B78 LVDS_B3- LVDS Display
Channel B
3(Negative)
Not
connected
nc nc
B79 LVDS_BKLT_EN LVDS Display
Backlight Enable
O-3.3
PD 4.75K. -
B80 GND (Fixed) Power Ground PWR - -
B81 LVDS_B_CK+ LVDS Display
Channel B Clock+ Not
connected nc nc
B82 LVDS_B_CK- LVDS Display
Channel B Clock- Not
connected nc nc
B83 LVDS_BKLT_CTRL LVDS Display
Backlight
Brightness
O-3.3
- -
