Kontron microETXexpress-PV User’s Guide
23
Pin Signal Description Type Terminati
on
Comment
B41 GND (Fixed) Power Ground PWR - -
B42 USB3- USB Data- Port #3
DP-I/O
- Hooked to USB
port #3 on the
ICH8M.
B43 USB3+ USB Data+ Port #3 -
B44 USB_0_1_OC# USB Over current
Pair 0/1
I-3.3 SUS
PU 3.3
SUS of
10K Hooked to over
current pin 0/1
of ICH8M.
B45 USB1- USB Data- Port #1
DP-I/O
- Hooked to USB
port #1 on the
ICH8M.
B46 USB1+ USB Data+ Port #1 -
B47 EXCD1_PERST# PCIe Express Card
1 Reset
O-3.3
- Connected to
ICH8M pin
GPIO6.
B48 EXCD1_CPPE# PCIe Express Card
1 Request
I-3.3
PU 3.3 of
10K Connected to
ICH8M pin
GPIO12.
B49 SYS_RESET# Reset button
input
I-3.3
PU 3.3
SUS of
10K -
B50 CB_RESET# Carrier Board
Reset
O-3.3 SUS
- -
B51 GND (Fixed) Power Ground PWR - -
B52 PCIE_RX5+ PCIe 5 Receive
Data+ Not
connected nc nc
B53 PCIE_RX5- PCIe 5 Receive
Data- Not
connected nc nc
B54 GPO1 General Purpose
Output 1
O-3.3
- Connected to
CPLD
B55 PCIE_RX4+ PCIe 4 Receive
Data+
DP-I
- -
B56 PCIE_RX4- PCIe 4 Receive
Data-
- -
B57 GPO2 General Purpose
Output 2
O-3.3
- Connected to
CPLD
B58 PCIE_RX3+ PCIe 3 Receive
Data+
DP-I
- -
B59 PCIE_RX3- PCIe 3 Receive
Data-
- -
B60 GND (Fixed) Power Ground PWR - -
B61 PCIE_RX2+ PCIe 2 Receive
Data+
DP-I
-
B62 PCIE_RX2- PCIe 2 Receive
Data-
-
B63 GPO3 General Purpose
Output 3
O-3.3
Connected to
CPLD
B64 PCIE_RX1+ PCIe 1 Receive DP-I - -
