Kontron microETXexpress-PV User’s Guide
50
date are set accordingly. Pressing F2 sets the date to the BIOS build date
and the hour is set to 00:00:00. The default values are reloaded and the
system will boot on the default bootable device.
5.6 General Purpose Input and Output (GPIO)
The microETXexpress®-PV COM provides eight GPIOs (always enabled)that can be
accessed through the module connector described in the pin-out lists, in
Section 4.1. The GPIO viewer can be enabled in the BIOS setup.
NOTE: GPIO cannot drive applications faster than 2 msec. Data transfer
rates up to 1 kHz maximum are recommended.
Table 19: GPIO COM Express Pin-Outs
Bit of GPIO
Port0
Function COM Express Pin
0 GPI0 A54
1 GPI1 A63
2 GPI2 A67
3 GPI3 A85
4 GPO0 A93
5 GPO1 B54
6 GPO2 B57
7 GPO3 B63
5.7 I 2
C
The microETXexpress®-PV COM integrates uses an I 2 C bus provided via the
Intel® ICH8M chipset. For the External I²C Speed it will always be 100kHz.
No multi-master support is available.
5.8 ACPI Suspend Modes and Resume Events
The microETXexpress®-PV COM supports the following suspend modes:
» S0 (Full on)
» S3 (Suspend to RAM)
» S4 (Suspend to Disk)
» S5 /WOL(power off, WOL enabled)
» S5 (power off, WOL disabled)
Events that Resume the System from S3
